ABB|70EB02B-E|Binary Input Module
Description
The 70EB02B-E is a binary input module designed for use in the PROCONTROL ---PS protection system. It facilitates the connection of digital inputs, enabling monitoring and control functions within the system.
Features
- Binary Input Module: Handles digital signals.
- Data Telegrams: Processes one telegram per module.
- LED Indicators: Front panel LEDs for status indication.
- Compact Design: Occupies minimal space within the rack.
Technical Specifications
- Inputs: 16 digital inputs for signal processing.
- Telegram Processing: One data telegram per module.
- Indicators: Front panel LEDs for indicating active inputs and operational status.
- Space Requirement: Occupies one module space (rack division).
- Interface Standard: Uses SEA standard interface for communication with the PROCONTROL ---PS bus.
- Power Supply: Requires 24V DC power supply.
- Monitoring: Capable of monitoring internal functions and signaling disturbances via diagnostic telegrams.
- Installation Flexibility: Can be plugged into any multi-purpose processing station of the PROCONTROL bus system.
- Addressing: Must be installed in even-numbered module addresses; the next higher address is used automatically without additional wiring.
- Data Transfer: Efficiently transfers data between connected modules and the system bus, ensuring reliable operation and event processing within the protection system.
