Yokogawa SAED5D High-Accuracy Data Acquisition Board
The Yokogawa SAED5D , also cataloged as the SAED5D High-Accuracy Data Acquisition System, operates as a dedicated hardware component for high-speed simultaneous analog signal digitizing and data streaming within Yokogawa measurement and control platforms.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | SAED5D |
| Brand | Yokogawa |
| Origin | Japan |
| Weight | 3.0 kg |
| Dimensions | Standard chassis-mount footprint |
| Operating Temp | Standard industrial cabinet range |
| Power Consumption | System bus powered |
| Analog Inputs | 10 channels |
| Analog Resolution | 20-bit |
| Sampling Rate | Up to 5 MS/s per channel (simultaneous) |
| Aggregate Sampling Rate | Up to 10 MS/s |
| Digital I/O | 16-bit digital inputs and outputs |
| Data Streaming Rate | Up to 10 MS/s |
| Onboard Storage | Up to 100 million data points |
| Communication Interface | Remote control and monitoring via Ethernet |
| Trigger Modes | Analog and digital triggering |
High-Resolution Sampling & HART Loop Signal Integrity
The 20-bit analog conversion architecture processes incoming field signals with channel-to-channel isolation to suppress high-frequency line noise and ground loops. Real-time high-speed data acquisition pipelines interface cleanly alongside standard 4-20 mA HART loop protocol lines, maintaining signal integrity across dense analog processing networks without cross-talk degradation or data frame corruption.
Frequently Asked Questions
Q: Does the SAED5D support simultaneous analog channel sampling?
A: Yes. All 10 analog input channels feature dedicated conversion hardware enabling simultaneous sampling at rates up to 5 MS/s per channel.
Q: How is high-speed transient data managed onboard before network transmission?
A: The board includes integrated onboard memory capable of storing up to 100 million data points for buffering high-speed burst acquisitions prior to Ethernet streaming.
Q: What network interface is utilized for remote acquisition control and parameter setting?
A: Remote control, data streaming, and hardware status monitoring are executed over a standard industrial Ethernet interface.
Field Installation Guidelines
- Securely mount the SAED5D hardware module into the designated system enclosure frame, verifying all grounding tabs maintain firm metal-to-metal electrical contact.
- Connect field analog signal lines using shielded twisted-pair cables to preserve 20-bit measurement resolution and prevent high-frequency noise pickup.
- Terminate cable shields at the dedicated single-point cabinet ground rail rather than at the board terminals to eliminate potential ground loop paths.
- Route industrial Ethernet cables away from high-voltage AC motor lines or inductive switching devices to prevent communication packet loss during 10 MS/s data streaming.
