Schneider |TSXDEY32D2| 32-Channel Isolated Discrete Input Module

SKU: TSXDEY32D2

Manufacturer: SCHNEIDER
Product No.: TSXDEY32D2
Condition：In stock
Product Type: 32-Channel Isolated Discrete Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months

Description

Schneider Electric TSXDEY32D2 is a 32-channel isolated discrete input module for the Modicon Premium automation platform, designed for industrial applications with 24 V DC input and high noise immunity.

Features

Compact digital input module with isolated inputs, fast response time, and integrated diagnostics; supports 24 V DC sensors with built-in compliance to EN/IEC 61131-2 Type 1.

Technical Specifications

Platform and I/O

Platform: Modicon Premium automation
Module Type: Discrete input module
Number of Inputs: 32 channels
Input Voltage: 24 V DC (positive)
Sensor Supply Range: 19–30 V DC
Input Current: 3.5 mA per channel

Signal Detection

Voltage State 1: ≥ 11 V
Current State 1: ≥ 3 mA
Voltage State 0: ≤ 5 V
Current State 0: ≤ 1.5 mA
Input Impedance: 6300 Ω at state 1

Performance

Response Time: ≤ 7 ms (typical: 4 ms)
Isolation Resistance: < 10 MΩ at 500 V DC
Dielectric Strength: 1500 V AC (50/60 Hz)

Electrical and Power

Power Consumption: 1 W + 0.1 W × active inputs
Current Consumption: 135 mA at 5 V DC, 160 mA at 24 V DC
Connector: HE-10

Physical and Environmental

Module Format: Standard
Weight: 0.3 kg

Certifications and Standards

Compliance: EN/IEC 61131-2, UL 508, CSA, IEC 60664
Certifications: CE, LR, BV, GL, DNV, ABS, RINA

Environmental Ratings

Operating Temp: 0…60 °C
Storage Temp: –25…70 °C
Humidity: 10–95% non-condensing
Altitude: Up to 2000 m
Protection Rating: IP20
Pollution Degree: 2

Packaging

Unit Type: PCE
Dimensions: 5.5 x 18 x 26 cm
Gross Weight: 412 g
