SCHNEIDER|BMXCPS3500|Power Supply Module

SKU: BMXCPS3500

Manufacturer: SCHNEIDER
Product No.: BMXCPS3500
Condition：In stock
Product Type: Power Supply Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 42g
Shipping port: Xiamen
Warranty: 12 months

Description
Schneider BMXCPS3500 is a power module for Modicon X80 series, incompatible with BMEXBP..02 backplane.

Features

Compact design
Multiple secondary power outputs

Technical Specifications

Product Series and Type
Modicon X80
Power Module

Backplane Compatibility
Not compatible with BMEXBP..02

Voltage and Input
Primary Voltage: 100...240 V AC
Main Voltage Limit: 85...264 V
Grid Frequency: 50/60 Hz
Network Frequency Limit: 47…63 Hz

Power and Current
Apparent Power: 0.12 kVA
Input Current: 0.52 A at 240 V, 1.04 A at 115 V
Max Inrush Current: 30 A at 120 V, 60 A at 240 V

Secondary Power Outputs
15 W 3.3 V DC for I/O logic
31.2 W 24 V DC for I/O modules and processor
21.6 W 24 V DC for sensors

Protection and Reliability
MTBF: 4300000 H
Internal Fuse for Main Circuit
Overload, Overvoltage, Short Circuit Protection for Secondary Circuits

Electrical Characteristics
I²t Activation: 1 A².s at 120 V, 3 A².s at 240 V
It Activation: 0.05 A.s at 120 V, 0.07 A.s at 240 V
Maximum Power Dissipation: 8.5 W

LED Indicators
Green LED for Backplane Voltage Normal
Green LED for Sensor Voltage

Environmental Conditions
Operating Temperature: 0…60 °C
Storage Temperature: -40…85 °C
Humidity: 5…95 % at 55 °C, non-condensing

Physical and Compliance
Weight: 0.36 kg
IP Rating: IP20
Compliance: 2014/35/EU, 2014/30/EU

Packaging Details
PCE Packaging: Height 13 cm, Width 15.5 cm, Length 15.5 cm, Gross Weight 530 g
S04 Packaging: Quantity 12, Height 30 cm, Width 40 cm, Length 60 cm, Gross Weight 7.520 kg
P06 Packaging: Quantity 48, Height 75 cm, Width 60 cm, Length 80 cm, Gross Weight 41 kg
