PanelView 1000 Standard | Allen-Bradley 2711-K10G8L1 Operator Terminal
The Allen-Bradley 2711-K10G8L1 is a PanelView 1000 Standard Operator Terminal equipped with a 10-inch grayscale display and a tactile keypad interface. Designed for industrial operator control stations, this discontinued HMI unit operates on a 24 VDC input voltage and features integrated Data Highway Plus (DH+) and RS-232 communication ports for legacy network connectivity.
Display and Operator Interface
The terminal features a 10-inch monochrome grayscale display with a resolution of 640 x 480 pixels, providing clear visual feedback for industrial processes. Operator inputs are executed via a dedicated physical keypad assembly rather than a touchscreen, ensuring reliable tactile operation in demanding plant floor environments.
Communication and Power
Connectivity options include a Data Highway Plus (DH+) port for peer-to-peer controller communication and an RS-232 port for printer or auxiliary device support. The unit is powered by a 24 VDC input power supply, making it suitable for control panels requiring low-voltage DC distribution.
| Parameter | Specification |
|---|---|
| Model | 2711-K10G8L1 |
| Brand | Allen-Bradley |
| Product Family | PanelView Standard Operator Terminals |
| Display Size | 10 in. |
| Display Color | Grayscale |
| Resolution | 640 x 480 |
| Input Type | Keypad |
| Communication Ports | DH+, RS-232 |
| Input Voltage | 24 VDC |
| Weight | 6.28 lbs (2.85 kg) |
| Product Lifecycle Status | Discontinued / Obsolete |
Frequently Asked Questions
Q: What communication protocols does the 2711-K10G8L1 support?
A: The terminal supports Data Highway Plus (DH+) for network communication and an RS-232 port for auxiliary connections such as printers.
Q: What power supply voltage is required for this operator terminal?
A: The unit operates on a 24 VDC input power source.
