Operator Terminal | Allen-Bradley 2711-K6C5L1
The Allen-Bradley 2711-K6C5L1 is a PanelView Standard operator interface terminal engineered to deliver real-time process visualization and control for industrial automation applications. Featuring a 5.7-inch color display with a resolution of 320 x 234 pixels, this HMI unit allows operators to effectively monitor system variables and interact with connected machinery using an integrated physical keypad.
Display and Operator Interface
The terminal is equipped with a color display measuring 5.7 inches across, providing clear and legible visual feedback for plant floor operations. Operator interaction is managed through a tactile keypad assembly, supporting direct data entry, screen navigation, and function execution in demanding industrial environments.
Communication and Power Configuration
For process communication, the unit utilizes an RS-232 port with DH-485 protocol support, enabling reliable data exchange with compatible controllers. It operates on a standard 24 VDC input power supply, maintaining an efficient and lightweight physical profile of 4.50 lbs for straightforward control cabinet installation.
| Parameter | Specification |
|---|---|
| Model | 2711-K6C5L1 |
| Brand | Allen-Bradley |
| Product Family | PanelView Standard (PanelView 600) |
| Product Type | Operator Interface Terminal |
| Display Size | 5.7 in. |
| Resolution | 320 x 234 pixels |
| Display Type | Color Display |
| Input Type | Keypad |
| Communication Ports | RS-232 (DH-485) |
| Input Voltage | 24 VDC |
| Weight | 4.50 lbs |
Frequently Asked Questions
Q: What type of display does the Allen-Bradley 2711-K6C5L1 utilize?
A: It features a 5.7-inch color display with a resolution of 320 x 234 pixels for clear visual monitoring.
Q: What communication protocol and port interface does this operator terminal support?
A: It supports RS-232 communication with DH-485 protocol capabilities for data exchange with automation controllers.
Q: What is the required input voltage for powering this unit?
A: The terminal operates on a standard 24 VDC input power supply.
