Honeywell|FC-TELD-0001| Earth Leakage Sensor

SKU: FC-TELD-0001

Manufacturer: Honeywell
Product No.: FC-TELD-0001
Condition：In stock
Product Type: Earth Leakage Sensor
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

HONEYWELL FC-TELD-0001 UIO Earth Leakage Sensor

Description
The HONEYWELL FC-TELD-0001 is a Universal Input Output (UIO) earth leakage sensor designed to detect residual currents in electrical systems.

Features
Offers 30 mA trip sensitivity for early fault detection. Operates on 230/400 VAC, supports up to 630 A. Functions in temperatures from -25°C to +70°C. Includes 5-second reset delay and auxiliary contact output. Low power consumption under 5 VA. Compact design (90 x 45 x 22.5 mm) for easy installation.

Technical Specifications

Rated Voltage: 230/400 VAC
Rated Current: Up to 630 A
Operating Temperature: -25°C to +70°C
Trip Sensitivity: 30 mA
Reset Delay: 5 seconds
Response Time: Less than 25 ms
Auxiliary Contact Output: 1 x SPDT, 2 A at 250 VAC
Power Consumption: Under 5 VA
Dimensions: 90 x 45 x 22.5 mm

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
