Honeywell |CC-TAIX11|redundant I/O Terminal Adapter (IOTA)

SKU: CC-TAIX11

Manufacturer: Honeywell
Product No.: CC-TAIX11
Condition：In stock
Product Type: redundant I/O Terminal Adapter (IOTA)
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

CC-TAIX11 is a redundant I/O Terminal Adapter (IOTA) for the Experion Series-C Analog Input Module. It provides connectivity and supports redundancy to ensure high availability in process control systems.

Features

Supports voltage, current inputs from transmitters.
Optional redundancy for enhanced reliability.
Extensive self-diagnostics capabilities.
Non-incendive power supply for field devices.
Fast loop scan for timely data acquisition.

Technical Specifications

Input Type: Voltage, current (2-wire or self-powered transmitters)
Channels: 16 (12 Single Ended / 4 Differential)
Common Mode Rejection Ratio: 70 dB at dc to 60 Hz (500 Ω source imbalance)
Common Mode Voltage: -6 to +5 V peak at dc to 60 Hz
A/D Converter Resolution: 16 bits
Input Range: 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 Ω)
Normal Mode Rejection Ratio: 19 dB at 60 Hz
Normal Mode Filter Response: Single-pole RC, -3 dB @ 6.5 Hz
Maximum Normal Mode Input: ±30 Volts (differential inputs, no damage)
Crosstalk: -60 dB at dc to 60 Hz (channel-to-channel)
Input Impedance (voltage inputs): > 10 MΩ powered
Input Scan Rate: 50 ms
Hardware Accuracy (@ CMV= 0 V): ±0.075% of full-scale (23.5°± 2°C), ±0.15% of full-scale (0 to 60°C)
Transmitter Field Power Conditioning: Individually protected current limiting circuits for Class 1, Div 2 non-incendive interfacing; no fusing required
Size: 9" (Redundant)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
