GE Fanuc|IC670GBI102|Bus Interface Unit

SKU: IC670GBI102

Manufacturer: GE Fanuc
Product No.: IC670GBI102
Condition：In stock
Product Type: Bus Interface Unit
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

A high-voltage Bus Interface Unit supporting hot insertion/removal of modules in I/O stations, providing power distribution, communication bus connectivity, and system configuration storage.

Features

Supports hot insertion/removal of J or later revision modules (with IC670CHS10x terminal blocks)
Dual Genius bus connections via 8 input terminals
Built-in overvoltage protection (disable via jumper)
Stores I/O station configuration parameters in terminal block
High reliability with long MTBF

Technical Specifications

Power Input:
- Nominal: 115VAC or 125VDC
- Range: 90–135VAC, 105–150VDC
- Frequency (AC): 47–63Hz
- Power: 48VA (115VAC), 24W (125VDC) max at full load
Output to I/O Modules:
- Voltage: 6.5VDC ±5%
- Current: 2A max
- Holdup Time: 20ms max (nominal input)
Inrush Current: 20A peak, 3ms max
Reliability:
- BIU: >183,000 hours MTBF (calculated)
- Terminal Block: >600,000 hours MTBF (calculated)
Terminal Block:
- Power Requirements: 16mA max
- Wire Size: Up to AWG #14 (2.1mm²) for power/ground; 2x AWG #14 for bus
- Torque: 9 in/lbs for terminal screws
Hot Insertion/Removal:
- Requires modules (suffix J+) and IC670CHS101/102/103 terminal blocks
- Not permitted in hazardous locations (power off required)
Grounding: Frame ground via ≤4-inch AWG #14 wire
