Bachmann|MX213/W|Motion Control Module

SKU: MX213/W

Manufacturer: Bachmann
Product No.: MX213/W
Condition：In stock
Product Type: Motion Control Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description
The Bachmann MX213/W is a high-performance motion control module designed for precise positioning and speed control in industrial automation applications, compatible with the M200 controller system.

Features

High-precision motion control for up to 4 axes
Integrated Safe Torque Off (STO) functionality
Supports various feedback systems including absolute encoders
Ethernet-based communication for real-time data exchange

Technical Specifications

Motion Control

Axes supported: Up to 4 axes
Feedback types: Incremental encoder, SinCos encoder, Resolver, SSI absolute encoder
Position resolution: up to 24 bits
Maximum frequency: 5 MHz per axis

Safety Features

Safe Torque Off (STO): SIL3/PLe certified
Emergency stop handling: Configurable via software

Communication Interfaces

Ethernet ports: 2x 10/100 Mbps
Fieldbus support: EtherCAT, CANopen
Data rates: Up to 100 Mbps

Power Supply

Input voltage: +24 V DC (+/- 10%)
Power consumption: Typ. 6 W

Environmental Conditions

Operating temperature: 0 °C to +50 °C
Storage temperature: -20 °C to +85 °C
Relative humidity: 5 % to 95 % RH noncondensing

Physical Characteristics

Dimensions: 110 x 119 x 61 mm
Weight: Approximately 500 g

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
