Bachmann|MC220|Industrial Quad-Core CPU Module

SKU: MC220

Manufacturer: Bachmann
Product No.: MC220
Condition：In stock
Product Type: Industrial Quad-Core CPU Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Bachmann MC220 Overview

The Bachmann MC220 is a high-performance industrial quad-core CPU module designed for real-time automation tasks, featuring up to 1.6 GHz clock speed and advanced multiprocessing capabilities in a compact, rugged design.

Features

Quad-core processor at up to 1.6 GHz
Real-time symmetric multiprocessing (SMP)
Fanless operation from -30 °C to +60 °C
Up to 2 GB DDR4 RAM, 4 GB Flash storage
3x Ethernet ports with IEEE 1588 support
CFast card slot for removable storage
Trusted Platform Module (TPM 2.0)

Technical Specifications

Processor

Architecture: x86 / Intel Atom
Clock frequency: 1.6 GHz
Cores: 4 physical
Hyper-Threading: Supported
Real-Time SMP: Yes with core reservation

Memory

Working memory: 2 GB DDR4
Retentive memory: 1 MB NVRAM
Internal storage: 4 GB pSLC Flash
Removable storage: CFast Type I slot

Interfaces

Ethernet: 3x 10/100/1000 Base-T (RJ45), AutoNegotiation, IEEE 1588
Serial: 1x RS232, 1x RS232/RS422/RS485
USB: 1x USB 3.0 (Type-A)

Performance & Power

Supply voltage: +5 V DC via M200 backplane
Power consumption: 15.9 W (+5 V / 3180 mA)
Reverse polarity protection: Yes (with NT255)

Environmental

Operating temperature: -30 °C to +60 °C
Humidity: 5 % to 95 % RH noncondensing
Optional ColdClimate version: Condensation-resistant coating
Protection class: IP20

Approvals & Standards

Certifications: CE, UKCA, cULus
Marine approvals: ABS, BV, DNV, KR, LR, NK, RINA

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
