Bachmann|FS221|FASTBUS Slave Module

SKU: FS221

Manufacturer: Bachmann
Product No.: FS221
Condition：In stock
Product Type: FASTBUS Slave Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

BACHMANN FS221/N 00016749-10 FASTBUS Slave Module

Description
BACHMANN FS221/N 00016749-10 is a FASTBUS slave module with integrated power supply, enabling long-distance, low-latency distribution of SubDevices in M200 automation systems via fiber optic links.

Features
Single fiber optic (FO) interface for FASTBUS communication.
Integrated power supply for remote I/O modules.
Supports up to 15 distributed SubDevices.
Connectable via LC patch cable or Harting PushPull® connector.
Minimal signal delay with cold-climate variants available.

Technical Specifications
• Fiber Optic Interface:

Connector Type: LC
Transmission Medium: Multimode fiber (50/125 μm or 62.5/125 μm)
Wavelength: 1310 nm
Maximum Distance: 2000 m per segment
Total Network Length: Up to 2300 m
Link Budget: >8 dB (3 dB reserve)
Max Stations: 16 (up to 10 per line)
• Integrated Power Supply:
Input Voltage: 24 V DC (18–34 V range)
Nominal Output Power: 18.25 W
Output Currents:
- +5 V: 3000 mA
- +15 V: 250 mA
- –15 V: 200 mA
Total power output must not exceed 18.25 W
• Diagnostics:
Hardware: Three-color LED for received light status
Software: Signal strength monitoring from 0% to 100%
• Environmental Ratings:
Operating Temperature: –30°C to +60°C
Storage Temperature: –40°C to +85°C
Humidity: 5%–95% RH, condensing and non-condensing
Pollution Degree: 2 (per IEC 60664-1)
• Approvals: CE, UKCA, cULus
