Bachmann|DI216|Digital Input Module

SKU: DI216

Manufacturer: Bachmann
Product No.: DI216
Condition：In stock
Product Type: Digital Input Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description
The Bachmann DI216 (Part No. 00009002-00) is a digital input module for the M200 control system, offering 16 isolated 24 V DC input channels for industrial automation sensor integration.

Features

16 galvanically isolated digital inputs
Compatible with 24 V DC nominal voltage (18–34 V DC range)
Supports interrupt inputs on channels 1 and 2
LED status indication per channel
Designed for harsh industrial environments

Technical Specifications

Input Configuration

Number of inputs: 16
Input groups: 2 (Channels 1–8 and 9–16)
Input type: Current-sinking logic > 2 mA (EN 61131-1 type 1)
Internal resistance: approx. 6 kΩ
Low-level threshold: –34 V to +5 V
High-level threshold: +15 V to +34 V
Filter delay: 3 ms typical
Signal delay: 50 µs typical

Isolation

Galvanic isolation from system: 300 V
Galvanic isolation between input groups: 500 V

Power Supply

Power via backplane: +5 V DC
Current consumption: 70 mA

Environmental Conditions

Operating temperature: –30 °C to +60 °C
Storage temperature: –40 °C to +85 °C
Humidity (operation): 5 % to 95 % RH noncondensing

Certifications

Compliant with CE, UKCA, cULus standards
Marine approvals: ABS, BV, DNV, LR, KR, NK, RINA
