Bachmann|CH221B| 11-Slot Backplane Module

SKU: CH221B

Manufacturer: Bachmann
Product No.: CH221B
Condition：In stock
Product Type: 11-Slot Backplane Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description
The Bachmann CH221B is an 11-slot backplane module designed for mechanical and electrical integration of M200 control system modules, serving as the controller's backbone.

Technical Specifications

Mechanical Design

Number of module slots: 11
Width: 55 mm × number of module slots (605 mm total)
Depth: 23 mm (including connector)
Height: 119 mm

Environmental Conditions

Operating temperature: -30 °C to +60 °C
- Vertical installation: -30 °C to +55 °C
Storage temperature: -40 °C to +85 °C
Operating humidity: 5 % to 95 % noncondensing
Storage humidity: 5 % to 95 % noncondensing

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
