Bachmann|AO208/I| Analog Input/Output Module

SKU: AO208/I

Manufacturer: Bachmann
Product No.: AO208/I
Condition：In stock
Product Type: Analog Input/Output Module
Product Origin: Austria
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description
The Bachmann AIO208 is a versatile analog input/output module offering 8 channels for measuring and outputting standard analog signals, suitable for industrial automation applications.

Features

Provides 8 channels for analog inputs/outputs
Supports various signal types including voltage, current, and temperature sensors
Configurable via the SolutionCenter engineering tool
High resolution with 16-bit input and 14-bit output

Technical Specifications

Channels

Number of channels: 8
Types: Analog inputs, outputs, temperature sensors

Signal Types

Voltage input range: ±10 V to ±10 mV
Current input range: 0(4) mA to 20 mA
Temperature sensors: Pt100/Pt1000 (2-, 3-, 4-wire), thermocouples (J, K, T, N, E, R, S, B)
Voltage output range: ±10 V
Current output range: 0(4) mA to 20 mA

Resolution and Accuracy

Input resolution: 16 bit with filter
Output resolution: 14 bit
Voltage accuracy at 25 °C:
- Range ±10 V: ±0.05 % FS
- Range ±1 V: ±0.05 % FS
- Range ±100 mV: ±0.05 % FS
- Range ±10 mV: ±0.2 % FS
Current accuracy at 25 °C:
- Range ±20 mA: ±0.1 % FS
- Range 0 mA to 20 mA: ±0.2 % FS
- Range 4 mA to 20 mA: ±0.2 % FS

Filter and Protection

Adjustable filter from 4 kHz to 0.5 Hz per channel
Overload and short circuit protection on all outputs
External voltage proof up to ±24 V
Galvanic isolation for system: 500 V

Environmental Conditions

Operating temperature: -30 °C to +60 °C
Storage temperature: -40 °C to +85 °C
Relative humidity: 5 % to 95 % noncondensing

Power Supply

Internal supply: Via BS2xx backplane
Internal current consumption: 80 mA
External voltage range: 18 V DC to 34 V DC
Typical external current consumption at 24 V: 200 mA without external load
