Allen-Bradley 2711P-K7C4D7 display system
The Allen-Bradley 2711P-K7C4D7, also cataloged as the 2711P-K7C4D7 operator interface terminal, operates as a dedicated hardware component for human-machine interface visualization and plant-floor data exchange within industrial control networks.
Suffix Breakdown & Model Matrix
The PanelView Plus 700 operator terminal utilizes a structured catalog nomenclature:
- 2711P-K7C4D7: PanelView Plus 700 terminal featuring a 6.5-inch color display, tactile keypad input, Ethernet, RS-232, and dual USB communication ports, driven by a 24 VDC logic module with 256 MB flash/RAM memory.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2711P-K7C4D7 |
| Brand | Allen-Bradley |
| Origin | USA |
| Weight | 2.49 kg |
| Dimensions | 356 mm x 279 mm x 203 mm |
| Operating Temp | 0 deg C to 55 deg C |
| Power Consumption | 70 W maximum (2.9 A at 24 VDC) |
| Display Type | Color active-matrix TFT |
| Resolution | 640 x 480 pixels |
| Memory | 256 MB non-volatile flash / RAM |
| Communication Ports | Ethernet (10/100 Mbps), RS-232, (2) USB ports |
| Input Voltage | 18-32 VDC (24 VDC nominal) |
Profinet / EtherNet/IP Deterministic Networks and I/O Integration
The terminal facilitates real-time data monitoring through high-speed backplane bus communication protocols and deterministic network links. It executes screen navigation and tag updates by polling connected programmable logic controllers over industrial Ethernet networks using EtherNet/IP protocols. Backplane bus communication velocity and firmware flash compatibility ensure synchronized alarm handling, user input validation, and graphical status rendering across distributed automation topologies without introducing packet latency.
Frequently Asked Questions
Q: Can USB peripherals be connected for local data logging and file transfer?
A: Yes, the dual USB 2.0 host ports support standard USB flash drives for log storage, application transfer, and firmware updates, as well as external input devices.
Q: What is the input voltage tolerance for safe continuous operation?
A: The terminal requires a 24 VDC nominal power supply, operating continuously within an input voltage range of 18 to 32 VDC.
Q: Is this logic module equipped with Windows CE desktop functionality?
A: Yes, the integrated 256 MB CE logic module provides a Windows CE operating system environment supporting runtime execution and network utility configuration.
Field Installation Guidelines
- Cut out the panel mounting aperture strictly according to manufacturer dimensional templates to ensure proper gasket compression and NEMA seal integrity.
- Secure the unit into the enclosure cutout using all provided mounting clamps, tightening them evenly around the bezel perimeter.
- Ground the 24 VDC power supply negative terminal and connect the frame ground terminal to the main system earth bus via a low-impedance conductor.
- Verify that power line polarity and voltage limits match the 18-32 VDC specification prior to energizing the module.
