Allen-Bradley 2711P-B6C5D8 PanelView Plus 6 Operator Interface

SKU: 2711P-B6C5D8

Manufacturer: Allen-Bradley
Product No.: 2711P-B6C5D8
Condition：In stock
Product Type: Operator Interfaces
Product Origin: USA
Payment:T/T, Western Union
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months

The 2711P-B6C5D8 is an Allen-Bradley PanelView Plus 6 600 operator interface terminal engineered for machine-level control and visualization in industrial automation systems. Running on the Windows CE 6.0 operating system, this unit provides real-time process monitoring through a 5.7-inch color display and flexible operator inputs.

Visualization and Dual Operator Interface

The terminal features a 5.7-inch active-matrix TFT color LCD with a resolution of 320 x 240 pixels. Operator input is achieved through a dual-entry configuration that combines an analog resistive touchscreen with an integrated physical keypad, accommodating both direct screen navigation and physical button operation.

Communication and System Power

System connectivity includes an RS-232 serial port for communication with PLCs and controllers, alongside USB host/device ports for connecting peripherals and transferring data. The module is powered by an external 24 VDC power supply operating within an input voltage range of 18 to 30 VDC.

Parameter	Specification
Model	2711P-B6C5D8
Brand	Allen-Bradley
Product Line	PanelView Plus 6 600
Operating System	Windows CE 6.0
Display Type	Color Active-Matrix TFT LCD
Display Size	5.7 inches
Resolution	320 x 240 pixels
Operator Input	Keypad and Touchscreen
Communication Ports	RS-232, USB
Input Voltage	24 VDC nominal (18 to 30 VDC range)
Weight	0.50 lbs

Frequently Asked Questions

Q: What operating system runs on the 2711P-B6C5D8 operator interface?A: The terminal runs on Microsoft Windows CE 6.0, providing the underlying platform for machine-level HMI applications.

Q: What power source is required to operate this PanelView Plus 6 model? A: The device requires a nominal 24 VDC power supply operating within an allowable DC input voltage range of 18 to 30 VDC.

Q: What input options does this model offer for operator interaction? A: This model features a dual-input setup combining an analog resistive touchscreen with a physical keypad.

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
