Allen-Bradley 2711-K6C9L1 Operator Terminal
The Allen-Bradley 2711-K6C9L1, also cataloged as the 2711-K6C9L1 operator terminal, operates as a dedicated hardware component for operator visualization, data entry, and RS-232 serial communication across automated control networks.
Suffix Breakdown & Model Matrix
- 2711: Designates the Allen-Bradley PanelView Standard operator interface hardware platform family.
- K6: Specifies the PanelView 600 platform configuration featuring a 5.7-inch color display and dedicated tactile keypad input layout.
- C9: Denotes a color display combined with RS-232 (DH-485 / DF1) communication and printer port capabilities.
- L1: Indicates the wide-range DC/AC input power configuration supporting 18-32 VDC and 85-264 VAC lines.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 2711-K6C9L1 |
| Brand | Allen-Bradley |
| Origin | United States |
| Weight | 32.00 lbs (14.51 kg gross shipping weight) |
| Dimensions | Standard PanelView 600 panel cutout enclosure profile |
| Operating Temp | 0 deg C to +50 deg C (32 deg F to 122 deg F) |
| Power Consumption | 18-32 VDC / 85-264 VAC, 50/60 Hz (1.9 A max at 24 VDC / 60 VAC) |
| Display Type | 5.7-inch color graphics display |
| Input Interface | Tactile membrane keypad with function keys |
| Communication Ports | RS-232 (DH-485 protocol support) and RS-232 printer port |
Deterministic Networks and Firmware Flash Compatibility
The terminal utilizes dedicated RS-232 communication drivers to establish reliable serial connectivity and protocol execution across Allen-Bradley SLC 500 and MicroLogix controller topologies. Firmware flash compatibility managed through PanelBuilder32 software ensures consistent runtime screen rendering, dynamic alarm logging, and high-velocity register polling over the serial link. Galvanic isolation and signal conditioning circuitry on the communication interface protect internal processing logic against ground loop potential differences and plant-floor electrical transients.
Frequently Asked Questions
Q: Can the 2711-K6C9L1 terminal be connected or disconnected while system power is active?
A: No. Primary supply power must be completely isolated and turned off before mounting or extracting the terminal unit to prevent electrical hazards and hardware damage.
Q: How are application runtime files transferred to this PanelView 600 model?
A: Compiled applications are downloaded directly through the RS-232 communication port or transferred offline using a compatible ATA flash memory card.
Field Installation Guidelines
- Cut the panel enclosure opening strictly according to the official PanelView 600 template dimensions, ensuring clean edges and removing all burrs or metal filings before installation.
- Inspect the perimeter neoprene gasket for proper, unbroken seating around the bezel edge before sliding the unit into the cutout to preserve NEMA Type 12, 13, and IP54/IP65 ingress ratings.
- Torque the panel mounting clips evenly in a crisscross pattern to achieve uniform compression against the enclosure wall without distorting the plastic front bezel.
- Connect a heavy-gauge copper grounding wire from the designated chassis ground stud directly to the main cabinet ground bus to mitigate high-frequency electrical noise.
