Allen-Bradley 2711-K10G9 PanelView 1000 Terminal
The Allen-Bradley 2711-K10G9 is a PanelView 1000 Standard Operator Terminal featuring a 10.1-inch grayscale display and a 16-key tactile keypad assembly (F1 to F16). Designed for industrial automation environments, this discontinued operator interface provides reliable visualization and control capabilities, equipped with integrated DeviceNet and RS-232 communication ports for seamless network integration.
Display and Operator Interface
The terminal features a 10.1-inch monochrome grayscale display with a resolution of 640 x 480 pixels, delivering clear visual feedback for operator tasks. A built-in LED backlight provides an estimated half-life of 50,000 hours, ensuring long-term operational visibility. Operator input is handled via a dedicated 16-function key keypad assembly, facilitating direct control without touchscreen dependency.
Memory and Communication
System performance is supported by an internal application memory configuration comprising 310 KB of runtime memory and 1008 KB of nonvolatile storage. Communication capabilities include a DeviceNet port for control network connectivity and an RS-232 port dedicated to printer support or DH-485 communications, allowing flexible integration into legacy control architectures.
Power and Enclosure Specifications
The unit operates on an input voltage range of 85 to 264V AC at an input frequency of 47 to 63 Hz. For physical protection, the enclosure carries NEMA Type 12, 13, and 4X (indoor use only) ratings along with IP54 and IP65 compliance, protecting internal components against dust, dirt, and light water splashes.
| Parameter | Specification |
|---|---|
| Model | 2711-K10G9 |
| Brand | Allen-Bradley |
| Product Family | PanelView Standard Operator Terminals |
| Display Size | 10.1 in. |
| Display Color | Grayscale |
| Resolution | 640 x 480 |
| Input Type | Keypad (16 Function Keys, F1…F16) |
| Communication Ports | DeviceNet, RS-232 (Printer / DH-485) |
| Application Memory | 310 KB runtime, 1008 KB nonvolatile |
| Input Voltage Range | 85…264V AC |
| Input Frequency | 47…63 Hz |
| Enclosure Rating | NEMA 12/13, 4X (Indoor), IP54, IP65 |
| Weight | 6.31 lbs (2.86 kg) |
| Product Lifecycle Status | Discontinued / Obsolete |
Frequently Asked Questions
Q: What communication protocols are supported by the 2711-K10G9?
A: The terminal supports DeviceNet for network communication along with an RS-232 port configured for printer output or DH-485 connections.
Q: What are the power requirements for this operator terminal?
A: The unit requires an AC power source ranging from 85 to 264V AC at a frequency of 47 to 63 Hz.
