Allen-Bradley 2711-B6C15L1 PanelView 600 Operator Interface
The Allen-Bradley 2711-B6C15L1 is a PanelView Standard operator interface designed to provide local control and real-time visualization for industrial automation systems. This 5.7-inch color display unit features a dual combination of a keypad and touch screen for flexible operator input. It communicates via ControlNet and RS-232 networks, operating on a 24 VDC input power supply.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 2711-B6C15L1 |
| Brand | Allen-Bradley |
| Series | PanelView Standard (PanelView 600) |
| Display Size | 5.7 inch |
| Display Resolution | 320 x 234 pixels |
| Display Type | Color Display |
| Input Method | Keypad & Touch |
| Communication Ports | ControlNet, RS-232 |
| Input Voltage | 24 VDC |
| Weight | 5.00 lbs |
Display and Operator Input
The unit combines a 5.7-inch color screen with a resolution of 320 x 234 pixels, allowing operators to monitor process variables, alarms, and system statuses. Input actions are supported through both tactile function keys and touch-sensitive screen areas, ensuring reliable operation even in demanding industrial environments where operators may wear gloves.
Communication and Power Configuration
Equipped with a built-in ControlNet communication port and an RS-232 interface, this terminal integrates smoothly into automation networks for real-time data exchange with programmable logic controllers. The device is powered by a 24 VDC nominal input voltage, fitting standard industrial control panel power distribution architectures.
Frequently Asked Questions
Q: What communication protocols does the 2711-B6C15L1 support?
A: This operator interface supports ControlNet communication and RS-232 serial connection for PLC integration and programming transfers.
Q: What type of power supply is required for this operator terminal?
A: The unit requires a 24 VDC input voltage source for standard industrial panel operation.
