Allen-Bradley 1794-IM16 FLEX I/O AC Input Module
The Allen-Bradley 1794-IM16 is a 16-point discrete AC input module engineered for the FLEX I/O distributed control platform. Designed to process 240 VAC signals, this open-style unit provides reliable status monitoring for industrial automation systems. It features a compact DIN rail mount construction with an IP20 protection rating, making it an efficient choice for control cabinet installations.
Channel Capacity and Voltage Rating
The module accommodates 16 discrete input channels operating at 240 VAC. This high-density channel configuration allows maintenance personnel to interface multiple high-voltage field devices efficiently while maintaining organized cabinet wiring and dependable system communication through the FLEX I/O backplane.
Mechanical and Environmental Design
Built for standard industrial enclosures, the open-style module features a lightweight footprint of 0.13 lbs and mounts directly onto DIN rails. Its IP20 ingress protection rating ensures finger-safe operation inside control panels, supporting secure and straightforward deployment for system integrators.
| Parameter | Specification |
|---|---|
| Model | 1794-IM16 |
| Brand | Allen-Bradley / Rockwell Automation |
| Product Family | FLEX I/O |
| Product Type | Discrete Input Module |
| Input Type | AC Discrete |
| Inputs | 16 Points |
| Nominal Input Voltage | 240 VAC |
| Enclosure Type | Open Style, IP20 |
| Mounting Style | DIN Rail Mount |
| Weight | 0.13 lbs |
Frequently Asked Questions
Q: What terminal bases are compatible with the 1794-IM16 module? A: The module requires a compatible FLEX I/O terminal base, such as the 1794-TB2, 1794-TB3, or 1794-TB3S, to establish secure field wiring connections.
Q: What type of signals does this module process? A: It processes 16 channels of 240 VAC discrete input signals from field devices like pilot lights, limit switches, and pushbuttons.
