ABB | PM866K01 | Processor Unit (CPU Controller)
SKU: PM866K01

  • Manufacturer: ABB

  • Product No.: PM866K01

  • Condition：In stock

  • Product Type: Processor Unit

  • Product Origin: Sweden

  • Payment:T/T, Western Union

  • Weight: 2000g

  • Shipping port: Xiamen

  • Warranty: 12 months

ABB PM866K01 Controller Technical Specifications

Specification Details
Product ID 3BSE076355R1 (PM867K01)
Redundancy No
High Integrity Yes
Clock Frequency 133 MHz
Performance 0.09 ms for 1000 boolean operations

Memory

Type Capacity
RAM 64 MB available for application
Flash Memory 46.559 MB for storage: No

Features and Benefits

  • ISA Secure certified
  • AC 800M High up to SIL 3 certified using PM865/SM811 or PM867/SM812
  • Supports S800 I/O High Integrity (PM865, PM866A, PM867, and PM891)
  • Configurable with 800xA control builder
  • Full EMC certification
  • TÜV Certified SIL 2 and SIL 3
  • Built-in redundant Ethernet communication ports

CPU Board Components

  • Microprocessor and RAM memory
  • Real-time clock
  • LED indicators
  • INIT push button
  • CompactFlash interface

Base Plate Connectivity

Port Type Details
Ethernet Ports Two RJ45 (CN1, CN2) for connection to the Control Network
Serial Ports Two RJ45 (COM3, COM4)
COM3 RS-232C port with modem control signals
COM4 Isolated port for connection of a configuration tool
Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

Check now

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
Check now
