ABB|DI810-EA 3BSE008508R2|Digital Input Module

SKU: DI810-EA 3BSE008508R2

Manufacturer: ABB
Product No.: DI810-EA 3BSE008508R2
Condition：In stock
Product Type: Digital Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 200g
Shipping port: Xiamen
Warranty: 12 months

ABB DI810-EA Digital Input Module

The ABB DI810-EA (3BSE008508R2) is a 16-channel 24 V DC digital input module, designed for industrial automation systems with group isolation and voltage supervision for reliable signal monitoring.

Description
This compact digital input module offers two isolated groups of 8 channels, each with voltage supervision, ensuring accurate detection of field signal status via the ModuleBus.

Features

Provides 16 current sinking digital inputs
Divided into two isolated groups of 8 channels
Includes voltage supervision per group
Features LED indicators for input status
Supports selectable filter times for noise reduction
Compatible with multiple module termination units (MTU)

Technical Specifications

Input voltage range:
- "0" signal: -30 to +5 V
- "1" signal: 15 to 30 V DC
Input impedance: 3.5 kΩ
Isolation: Groupwise isolated from ground
Filter times: Selectable at 2, 4, 8, or 16 ms
Power dissipation: Typically 1.8 W
Current consumption: 50 mA @ +5 V Modulebus
Dimensions:
- Width: 45 mm
- Height: 119 mm
- Depth: 102 mm (111 mm with connector)
Weight: 0.15 kg

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
