ABB|CI871AK01 3BSE092693R1|PROFINET IO Communication Interface

SKU: CI871AK01 3BSE092693R1

Manufacturer: ABB
Product No.: CI871AK01 3BSE092693R1
Condition：In stock
Product Type: PROFINET IO Communication Interface
Product Origin: USA
Payment:T/T, Western Union
Weight: 3300g
Shipping port: Xiamen
Warranty: 12 months

ABB CI871AK01 3BSE092693R1 PROFINET IO Communication Interface

Description
ABB CI871AK01 is a PROFINET IO master communication module for AC 800M controllers, enabling Ethernet-based connectivity to industrial automation devices.

Features

Supports PROFINET IO protocol as a master device
Enables hot-swap replacement
Provides module redundancy support
Connects via RJ45 Ethernet (10/100 Mbps)
Requires connection through an Ethernet switch

Technical Specifications

Type: PROFINET IO Communication Module
Protocol: PROFINET IO
Transmission Speed: 10 / 100 Mbit/s
Connectors: 1 x RJ45 (CH1 used)
Supported Systems: System 800xA 6.0.3.3 and later
CEX Bus Units Max: 12
Power Supply: +24 V DC via CEX-Bus
Current Consumption: 160 mA typ.
Operating Temperature: +5 °C to +55 °C
Storage Temperature: -40 °C to +70 °C
Altitude Max: 2000 m
Humidity: 5–95% RH, non-condensing
Pollution Degree: Class 2
Corrosion Protection: ISA 71.04 G3 compliant
Protection Rating: IP20
Certifications: CE, UL 61010-1, UL 60079-15, cULus Class 1 Zone 2
Marine Certificates: DNV-GL (pending: ABS, BV, LR)
Dimensions:
- Width: 59 mm
- Height: 185 mm
- Depth: 127.5 mm
Weight: 700 g (with baseplate)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
