ABB Bailey|IEPMU01|Power Mounting Unit

SKU: IEPMU01

Manufacturer: ABB
Product No.: IEPMU01
Condition：In stock
Product Type: Power Mounting Unit
Product Origin: USA
Payment:T/T, Western Union
Weight: 1200g
Shipping port: Xiamen
Warranty: 12 months

ABB IEPMU01 Power Mounting Unit

Description
ABB IEPMU01 is a power mounting unit designed for Infi 90 systems, providing secure installation and electrical integration for compatible power modules.

Features

Designed for structured mounting of power modules
Supports centralized power distribution
Fits standard 19-inch industrial control cabinets

Technical Specifications

Mounting and Compatibility

Mounting Type: Standard 483 mm (19 in.) cabinet
Compatible Modules: IEPAS02, IEPDS01/02, IEPAF02, IEPDF01/02

Power Distribution

Primary Input: 120/240 VAC or 24/48 VDC
Regulated Output Voltages: +5 VDC, +15 VDC, –15 VDC, +24 VDC
Maximum Current Ratings
- +5 V: 201 A per unit
- +15 V / –15 V: 1.6 A per unit
- +24 V: 8 A per unit

Environmental Conditions

Operating Temperature: 0°C to 70°C (32°F to 158°F)
Storage & Transport Temperature: –40°C to 85°C (–40°F to 185°F)
Humidity Tolerance: Up to 95% non-condensing

Certifications and Compliance

Meets IEC 1000.x and CISPR11 electromagnetic compatibility standards
CSA certified for nonhazardous locations
CE marked with compliance to EMC Directive 89/336/EEC
Flammability Rating: UL94 V0 to V2 materials

Physical Characteristics

Dimensions: 483 mm x 178 mm x 304 mm (19 in. x 7 in. x 12.2 in.)
Weight: 3.63 kg (8.0 lb.)
