GE Fanuc|IC694CEE001|RX3i Carrier/Expansion Module
GE Fanuc IC694CEE001 RX3i Carrier/Expansion Module
Description
GE Fanuc IC694CEE001 is a single-slot RX3i carrier/expansion module with integrated PROFINET interface and redundant 24 VDC power inputs, designed to enhance system availability and support critical applications.
Features
Enables addition of a second RX3i I/O module when used with IC695CEP001 carrier.
Provides superior uptime with redundant 24 VDC power supply inputs.
Supports seamless integration of RX3i and Series 90-30 I/O modules.
Performs remote I/O functions including input/output scanning and data publishing.
Monitors PROFINET communication and publishes fault diagnostics to controller.
Technical Specifications
General
- Module Type: Carrier/Expansion Module
- Mounting: DIN Rail or Panel
- Dimensions: 177.2 x 51 x 35 mm (6.98” x 2.01” x 1.38”)
Power
- Power Inputs: Dual redundant 24 VDC
- Input Voltage Range: 19.2 to 30 VDC
Connectivity
- Ethernet Ports: None (relies on CEP001)
- USB Port: None
- IP Addresses: 1 (supports CIDR)
- MAC Addresses: 3 (assigned via CEP001)
PROFINET
- PROFINET Version: 2.3 Class A IO-Device
- I/O Update Rates: Configurable from 1ms to 512ms
- PNS Status & Control Bits: 32 input, 32 output bits
I/O Capacity
- Maximum I/O Modules per Station: 2 (when paired with IC695CEP001)
- Total I/O Data per Station: 1024 bytes (512 bytes input, 512 bytes output)
