Yokogawa|ADMAGAE|Electromagnetic Flowmeter
SKU: ADMAGAE

  • Manufacturer: Yokogawa

  • Product No.: ADMAGAE

  • Condition：Persediaan

  • Product Type: Electromagnetic Flowmeter

  • Product Origin: Japan

  • Payment:T/T, Western Union

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

  • The YOKOGAWA ADMAG AE is an electromagnetic flowmeter designed for precise flow measurement of conductive fluids in various industrial applications.

Features

  • Highly accurate and reliable flow measurement.
  • Robust design for harsh environments.
  • Easy installation and maintenance.

Technical Specifications

General

  • Minimum conductivity: 5 µS/cm.
  • Fluid temperature: -10°C to 160°C.
  • Ambient temperature: -20°C to 60°C.
  • Power supply: 100–240 V AC (50/60 Hz) or 24 V DC.

Accuracy

  • Flow rate accuracy: ±0.5% of reading (velocity ≥ 0.5 m/s).
  • Repeatability: ±0.1% of reading.

Size and Flow Range

  • Nominal size: 2.5 mm to 500 mm.
  • Flow velocity range: 0.3 m/s to 10 m/s.
  • Maximum flow: 0.025 m³/h (2.5 mm) to 1413 m³/h (500 mm).

Pressure

  • Maximum pressure: 4 MPa (size ≤ 200 mm), 1.6 MPa (size ≥ 250 mm).
  • Pressure loss: Negligible (<0.01 MPa at 1 m/s).

Materials

  • Lining: PTFE (standard), polyurethane, or ceramic.
  • Electrode: Stainless steel 316L, Hastelloy C, or titanium.
  • Housing: Aluminum alloy, corrosion-resistant coating.

Output

  • Analog output: 4–20 mA DC.
  • Pulse output: 0.1–1000 Hz, max 30 V DC, 200 mA.
  • Communication: HART protocol (optional).

Electrical

  • Power consumption: ≤ 20 W (AC), ≤ 10 W (DC).
  • Insulation resistance: ≥ 100 MΩ at 500 V DC.
  • Dielectric strength: 1500 V AC for 1 minute.

Installation

  • Pipe connection: Flange (JIS, ANSI, DIN standards).
  • Mounting: Horizontal or vertical (with upward flow).
  • Protection: IP67 (dust-tight, water-resistant).
