Schneider Electric BMEP58CPROS3 Processor Module

Description
Schneider Electric BMEP58CPROS3 is a high-availability processor module for Modicon M580 ePAC systems, designed for advanced automation with integrated safety and robust environmental performance.

Features
High-performance controller with SIL 3 safety certification and PL = e compliance. Features embedded diagnostics, secure communications, and conformal coating for harsh industrial environments.

Technical Specifications

• Product Range: Modicon M580
• Module Type: BMEP58CPROS3
• Power Consumption: 295 mA at 24 V DC (rack-powered)
• MTBF: 946,000 hours
• Operating Temperature: -25–60 °C
• Storage Temperature: -40–85 °C
• Relative Humidity: 5–95% @ 55 °C, non-condensing
• Altitude: Up to 5000 m (derated above 2000 m)
• IP Rating: IP20
• Environmental Protection: Conformal coated; resistant to dust, salt, sand, gas, mold, and fungal spores
• Mechanical Robustness: Vibration resistance 3 gn, Shock resistance 15 gn
• Safety Certification: SIL 3 (IEC 61508), PL = e (ISO 13849-1)
• Hazardous Location: Class I Division 2, ATEX Zone 2/22, IECEx Zone 2/22
• Certifications: CE, UL, CSA, RCM, EAC, TÜV, Merchant Navy
• Standards: IEC 61131-2, IEC 61010-2-201, IEC 61850-3, IEC 60079-0
• Compliance Directives: EMC 2014/30/EU, Machinery 2006/42/EC, ATEX 2014/34/EU
• LED Indicators: RUN (green), ERR (red), DL (green), SRUN (green), SMOD (green)
• Net Weight: 0.849 kg
• Packaging:
  • Single: 17.9 × 25.2 × 8.7 cm, 843 g
  • Multi: 6 units, 30.0 × 40.0 × 30.0 cm, 5.452 kg
