SCHNEIDER|XBTGT5230| Advanced Touchscreen Panel

SKU: XBTGT5230

Manufacturer: SCHNEIDER
Product No.: XBTGT5230
Condition：In stock
Product Type: Advanced Touchscreen Panel
Product Origin: USA
Payment:T/T, Western Union
Weight: 75g
Shipping port: Xiamen
Warranty: 12 months

Schneider Electric XBTGT5230 Advanced Touchscreen Panel

Description
Schneider Electric XBTGT5230 is an advanced touchscreen HMI panel from the Harmony XBTGT range, designed for industrial automation control and monitoring.

Features

10.4-inch backlit color STN LCD with analog touch panel
Equipped with Vijeo Designer configuration software and Harmony OS
Supports multiple fieldbus protocols and features dual USB 1.1 ports
CompactFlash card slot and fieldbus communication card support

Technical Specifications

Display: 10.4-inch, 640 x 480 pixels (VGA), 4096 colors
Touch Resolution: 1024 x 1024 (analog resistive)
Brightness & Contrast: 8 adjustable levels via touch
Processor: RISC CPU, 266 MHz
Memory: 512 KB battery-backed SRAM, 32 MB Flash EPROM
Real-Time Clock: Built-in
Storage: 1 CompactFlash slot (≥1 GB)
Power: 24 V DC (19.2–28.8 V), 26 W, 30 A inrush current
Operating Temperature: 0–50 °C (32–122 °F)
Storage Temperature: -20–60 °C (-4–140 °F)
Humidity: 10–90% non-condensing
Supply Voltage: 24 V DC
Interfaces:
- 1 x RJ45 Ethernet (10/100BASE-TX)
- 1 x RS232/RS422/RS485 (SUB-D 9 male)
- 1 x RS485/MPI (RJ45)
- 2 x USB Type A (V1.1)
- Digital I/O, audio, power terminal blocks
Communication Protocols: Modbus, Modbus TCP, Modbus Plus, FIPWAY, Uni-TE, and third-party protocols (Siemens, Allen-Bradley, Omron, Mitsubishi)
Mechanical: Flush mounting, 4 spring or screw clamps, aluminum front
Dimensions: 313 x 239 x 56 mm (12.3 x 9.4 x 2.2 in)
Weight: 3 kg (6.6 lb)
Enclosure Rating: IP65 (front), IP20 (rear), NEMA 4X (front)
Certifications: CE, cULus, ATEX Zone 2/22, FCC Class A, C-tick
Standards: IEC 61131-2, UL 508, UL 1604, CSA C22.2 No 14
Backlight Life: 54,000 hours

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
