SCHNEIDER|TSXETY4103|Ethernet TCP/IP Module

SKU: TSXETY4103

Manufacturer: SCHNEIDER
Product No.: TSXETY4103
Condition：In stock
Product Type: Ethernet TCP/IP Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 75g
Shipping port: Xiamen
Warranty: 12 months

Schneider Electric TSXETY4103 Ethernet TCP/IP Module

Description
Schneider Electric TSXETY4103 is a high-performance Ethernet communication module for Modicon Premium automation systems, supporting 10/100 Mbit/s data rates and TCP/IP-based industrial protocols.

Features

Supports Modbus TCP, Uni-Telway, SNMP, SMTP, and I/O scanning
Built-in web server (等级B30) for remote monitoring
LED indicators for network status, activity, and faults
Compatible with PL7 Pro and Unity Pro software

Technical Specifications

Interface: RJ45, 10BASE-T/100BASE-TX
Transmission rate: 10/100 Mbit/s
Max connections: 64
Communication services: bandwidth management, FDR server, global data, Modbus TCP messaging
Power supply: via rack
Current consumption: 360 mA at 5 V DC
Web features: device monitoring, data editor via PC terminal

Physical & Environmental

Module format: Standard
Product weight: 0.34 kg
Package dimensions: 26.0 x 18.0 x 5.5 cm
Package weight: 426 g
Operating temperature: 0 to 60 °C
Humidity: 10–95% non-condensing at 60 °C
Protection rating: IP20

Compliance & Certifications

Standards: UL 508, CSA 1010-1, EN 61131-2, FM Class I Div 2 Groups A, B, D
Marking: CE

Packaging Details

Package type 1: PCE, 1 unit per box
Package type 2: S04, 12 units per box
Bulk packaging dimensions: 60 x 40 x 30 cm
Bulk net weight: 5.991 kg

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
