Schneider |TSXETG100|Ethernet Modbus Gateway/Router

SKU: TSXETG100

Manufacturer: SCHNEIDER
Product No.: TSXETG100
Condition：In stock
Product Type: Ethernet Modbus Gateway/Router
Product Origin: USA
Payment:T/T, Western Union
Weight: 100g
Shipping port: Xiamen
Warranty: 12 months

Description

Schneider Electric TSXETG100 is an Ethernet Modbus gateway/router designed for seamless communication between Ethernet and Modbus-compatible devices within the ConneXium product range.

Features

Compact industrial gateway with embedded web server, SNMP support, IP filtering firewall, and password protection; enables diagnostics and register access via built-in web pages.

Technical Specifications

Platform and Connectivity

Product Range: ConneXium
Device Type: Ethernet Modbus gateway/router
Target Devices: All Modbus-standard compatible products
Supported Protocols: Ethernet TCP/IP, Modbus RTU/ASCII
Maximum Connected Devices: Up to 32 on Modbus serial link

Communication Interfaces

Ethernet Port: RJ45, 10BASE-T/100BASE-TX (1 twisted pair)
Serial Ports:
- 5-pin removable terminal block: RS485 (Modbus RTU/ASCII, up to 57.6 kbps)
- Mini switch port: RS485 (Modbus RTU/ASCII, up to 57.6 kbps)
- RJ45: RS232 (up to 38.4 kbps)

Network Services

Web Server: B10 class – predefined pages for diagnostics and Modbus register access
SNMP Agent: For device management
Security: Built-in firewall (IP filtering), password protection
Boot Protocol: BOOTP, FDR client

Power Supply

Rated Voltage: 24 V DC
PoE Support: IEEE 802.3af compliant

Indicators and Design

LEDs:
- Ethernet: LK, RX, TX, 100
- Serial: RS485 RX, TX

Physical and Installation

Mounting: Symmetrical DIN rail
Dimensions: 72 mm (W) × 81 mm (H) × 76 mm (D)
Weight: Not specified

Environmental and Certifications

Operating Temp: 0…60 °C
Humidity: 5–95% at 40 °C non-condensing
