SCHNEIDER|TSX572623|Double-Format PL7 Processor

SKU: TSX572623

Manufacturer: SCHNEIDER
Product No.: TSX572623
Condition：In stock
Product Type: Double-Format PL7 Processor
Product Origin: USA
Payment:T/T, Western Union
Weight: 75g
Shipping port: Xiamen
Warranty: 12 months

Schneider Electric TSX572623 Double-Format PL7 Processor

Schneider Electric TSX572623 is a double-format processor for the Modicon Premium Automation platform, supporting PL7 Junior/Pro software and featuring integrated Ethernet and serial communication.

High-performance processor with 1024 I/O capacity, 48 Kwords RAM, PCMCIA expandable memory, and dual communication ports.

Technical Specifications

Processing & Memory

Internal RAM: 48 Kwords (program and data, without PCMCIA)
PCMCIA Support: 160 Kwords program, 2688 Kwords data storage
Execution Speed: 0.19 µs (Boolean, no card), 0.25 µs (fixed arithmetic), 2.6 µs (floating point)
Instructions per ms: Up to 4.76 Kinst/ms (100% Boolean, no card)

I/O & System Capacity

Discrete I/O Capacity: 1024 points
Analog I/O Capacity: 80 channels
Racks Supported: 16 (4/6/8 slots), 8 (12 slots)
Total Slots: 64, 96, or 128
Process Control: Up to 30 simple loops
Application-Specific Channels: 24

Communication

Integrated Ports: 1x Ethernet TCP/IP (RJ45, 10/100 Mbit/s), 1x non-isolated serial (mini DIN, 19.2 kbit/s)
Fieldbus Support: 1 fieldbus module, 4 AS-Interface, or 1 CANopen

Application Structure

Tasks: 1 master, 1 fast, 64 event tasks
System Overhead: 1 ms (master), 0.35 ms (fast task)

Electrical & Mechanical

Current Consumption: 1110 mA at 5 V DC
Module Format: Double
Weight: 0.76 kg (1.68 lb)
IP Rating: IP20
Pollution Degree: 2
Protective Treatment: TC

Environmental

Operating Temperature: 0–60 °C (32–140 °F)
Storage Temperature: -25–70 °C (-13–158 °F)
Humidity: 10–95% non-condensing (operation)
Altitude: Up to 2000 m (6561.68 ft)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
