SCHNEIDER|BMXCPS2000| Power Supply Module

SKU: BMXCPS2000

Manufacturer: SCHNEIDER
Product No.: BMXCPS2000
Condition：In stock
Product Type: Power Supply Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 42g
Shipping port: Xiamen
Warranty: 12 months

Product Description
Schneider Electric BMXCPS2000 power supply module for Modicon X80 automation platform with dual isolated outputs and integrated diagnostics.

Features

Dual 24 V DC outputs for sensors and I/O modules
Built-in overload, overvoltage, and short-circuit protection
LED indicators for voltage status and reset button for cold start

Technical Specifications

Platform compatibility: Modicon X80
Input voltage: 100–240 V AC (range: 85–264 V)
Frequency: 50/60 Hz (47–63 Hz)
Inrush current:
- 30 A at 120 V
- 60 A at 240 V
I²t rating: 12 A²·s at 240 V
Power consumption:
- Max output power: 10.8 W (sensor), 16.8 W (I/O and CPU), 8.3 W (logic)
- Max input power: 8.5 W
Output current:
- 0.45 A at 24 V sensor
- 0.7 A at 24 V I/O and processor
- 2.5 A at 3.3 V logic
MTBF: 4,638,000 hours
Protection features:
- Internal fuse (primary side)
- Overload, overvoltage, short-circuit protection (secondary side)
Isolation voltage:
- 1500–2300 V between primary and secondary
- 1500 V between circuits and ground
Insulation resistance: ≥ 100 MΩ
Environmental ratings:
- Operating temp: 0–60 °C
- Storage temp: -40–85 °C
- Humidity: 5–95% RH non-condensing
- IP rating: IP20
- Altitude: Up to 2000 m (derated up to 5000 m)
Mechanical specs:
- Weight: 0.3 kg
- Protection coating: TC
- Vibration: 3 gn
- Shock: 30 gn
Certifications: CE, UL, CSA, EAC, RCM
Packaging 1:
- Unit type: PCE
- Quantity: 1
- Dimensions: H 13.5 cm x W 15.4 cm x L 16.4 cm
- Weight: 481 g
Packaging 2:
- Unit type: S04
- Quantity: 12
- Dimensions: H 30 cm x W 40 cm x L 60 cm
- Weight: 6.438 kg
Packaging 3:
- Unit type: P06
- Quantity: 48
- Dimensions: H 75 cm x W 60 cm x L 80 cm
- Weight: 35.804 kg
