Honeywell 10313/1/1 Termination Module
Configured for power conditioning and watchdog signal routing in process safety platforms, the Honeywell 10313/1/1 (10313/1/1 Termination Module) provides direct physical/electrical execution.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 10313/1/1 |
| Brand | Honeywell |
| Origin | Standard Industrial Manufacturing |
| Weight | 1.5 kg (Parcel Weight), 5 kg (Shipping Weight) |
| Dimensions | Standard Terminal Module Chassis (Parcel Dim. Weight: 4 kg) |
| Operating Temp | 0 deg C to 60 deg C |
| Power Consumption | 5 VDC + Watchdog Distribution (Conformal Coated) |
| Approvals | CE, TÜV, UL |
4-20 mA HART Loop Protocol and Channel Isolation
The termination assembly distributes internal 5 VDC operating rails alongside dedicated watchdog signal channels across system backplanes. Integrated channel-to-channel isolation prevents cross-talk and common-mode electrical noise from affecting adjacent control nodes. Conformal coating (CC) protects exposed circuit paths from chemical contaminants and atmospheric humidity, preserving loop integrity in process environment enclosures.
Frequently Asked Questions
Q: What is the primary functional role of the Honeywell 10313/1/1 termination module?
A: The module distributes 5 VDC logic power and watchdog control signals across the system backplane to monitor central processing integrity and power rail status.
Q: Does the 10313/1/1 module include environmental protection features?
A: Yes, the unit comes standard with conformal coating (CC) to resist airborne moisture, dust, and aggressive atmospheric contaminants.
Field Installation Guidelines
- Mount the module firmly into its assigned rack or termination panel slot to ensure full backplane connector engagement.
- Connect power supply feed wiring according to termination diagrams, verifying stable 5 VDC levels before energizing downstream modules.
- Maintain clear physical separation between low-voltage watchdog distribution lines and high-voltage AC power wiring inside the cabinet.
- Ground all field cable shields at designated grounding bars to prevent transient noise interference across the signal distribution network.
