GE Fanuc|IC200ALG261|Analog Input Module

SKU: IC200ALG261

Manufacturer: GE Fanuc
Product No.: IC200ALG261
Condition：In stock
Product Type: Analog Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 410g
Shipping port: Xiamen
Warranty: 12 months

GE Fanuc IC200ALG261 Analog Input Module

Description
The GE Fanuc IC200ALG261 is an 8-channel, 15-bit differential voltage analog input module for the VersaMax system, powered by the backplane with no external power required for module operation.

Features

Eight differential voltage input channels in one group
15-bit converter resolution with software-configurable input range
Backplane-powered; no external power needed for module
LED indicators for diagnostics and status monitoring
Supports shielded twisted-pair wiring with source or module grounding
Compatible with PLC CPU firmware 2.1+ and EBI001 Ethernet NIU 1.10+
Accepts auxiliary I/O terminal strip for additional shield connections

Technical Specifications

Number of Channels: 8 differential inputs (single group)
Input Type: Voltage, differential
Voltage Range: -10 to +10 VDC
Resolution: 15-bit
Update Rate: 7.5 ms per 8-channel scan
Isolation: 250 VAC continuous (input to logic)
Power Consumption: 200 mA maximum from +5V backplane
