GE Fanuc|IC670MDL241|Discrete Input Module

SKU: IC670MDL241

Manufacturer: GE Fanuc
Product No.: IC670MDL241
Condition：In stock
Product Type: Discrete Input Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description
A 16-point, 240VAC discrete input module with 2 isolated groups of 8 inputs, powered by BIU and external 240VAC supply, designed for GE Field Control systems.

Features

16 discrete inputs in 2 isolated groups (8 points/group)
LED indicators for input status (on/off) and power (PWR)
Input filtering via capacitor-resistor network
Optoisolation between field inputs and logic components
Separate external power for each isolated group

Technical Specifications

Input Points: 16 (2 groups of 8, isolated)
Power Supply:
- BIU power supply: Drives module logic
- External power: 240VAC (0–265VAC operating range) per isolated group
Input Voltage:
- On-state: 155–265VAC
- Off-state: 0–40VAC
Input Impedance:
- 60Hz: 38.5kΩ
- 50Hz: 46.3kΩ
Input Current:
- On-state: 4–10mA
- Off-state: 0–1.5mA
Response Time:
- On: Max 20ms
- Off: Max 20ms
BIU Power Draw: Max 77mA
Isolation: Optoisolators between field inputs and module logic
Operating Voltage Range: 0–265VAC (field inputs)
