GE Fanuc|IC670ALG230J|Base Converter Module

SKU: IC670ALG230J

Manufacturer: GE Fanuc
Product No.: IC670ALG230J
Condition：In stock
Product Type: Base Converter Module
Product Origin: USA
Payment:T/T, Western Union
Weight: 2000g
Shipping port: Xiamen
Warranty: 12 months

Description

A high-level analog input base converter module with 8 differential inputs, configurable for voltage/current, supporting expansion to 120 inputs via expander modules.

Features

8 individually configurable voltage/current differential inputs
Supports ±10V unipolar/bipolar signals and 4–20mA current loops
User scaling per channel; expander modules scaled per module
Fast update rate (2.4ms per channel without expanders)
Expansion port for daisy-chaining up to 7 expander modules
No jumpers/DIP switches; software configuration via DOS/Windows tools

Technical Specifications

Inputs: 8 differential (Base); total system up to 120 inputs (8 + 7×16 expander channels)
Voltage Range: ±10V, ±5V, 0–10V, 0–5V (configurable)
Current Range: 4–20mA (with 250Ω internal load)
Resolution: 14 bits (16,384 steps) + oversampling enhancement
Update Rate:
- Base channels: 2.4ms (no expanders), 2.8ms (with expanders)
- Expander channels: 45ms per channel (1 expander), up to 314ms (7 expanders)
Expansion:
- 7 expander modules max (IC670ALG440 current/IC670ALG441 voltage)
- 16 inputs per expander, daisy-chained via expansion bus
Isolation: Optical isolation between inputs and backplane
Power:
- Backplane: 6.5VDC ±5%, 1.4A max (24VDC BIU)
- Field wiring: Shielded twisted pair, AWG #14–22
Mechanical:
- Keying: J-type for hot swap compatibility
- Terminal block: 40-pin, accepts 2 wires per terminal (AWG #14 max)

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
