Emerson|A9530V3|Wireless Vibration Monitor

SKU: A9530V3

Manufacturer: Emerson
Product No.: A9530V3
Condition：In stock
Product Type: Wireless Vibration Monitor
Product Origin: USA
Payment:T/T, Western Union
Weight: 550g
Shipping port: Xiamen
Warranty: 12 months

Description
The Emerson A9530V3 is an advanced Wireless Vibration Monitor designed for comprehensive machinery health monitoring, utilizing WirelessHART® technology to provide high-resolution vibration and temperature data with embedded prescriptive analytics.

Features

Provides triaxial vibration, temperature, and PeakVue™ measurements
Features embedded prescriptive analytics for actionable diagnostics
Offers long battery life up to 5 years for reduced maintenance
Suitable for hazardous environments with robust design

Technical Specifications

Data Acquisition:
- Vibration Overall X/Y: Up to 16g’s, Fmax 1,000 Hz, Sampling Rate 2.6 kHz
- Vibration Overall Z: Up to 80g’s, Fmax 20,000 Hz, Sampling Rate 51.2 kHz
- PeakVue Z: Up to 80g’s, Fmax 5,000 Hz, Sampling Rate 51.2 kHz
- Temperature Range: -40°C to 85°C
Device Variables:
- Z-axis Overall, X-axis Overall, Y-axis Overall, Z-axis PeakVue, Machine Temperature, Supply Voltage
Wireless Protocol:
- Standard: IEC 62591 WirelessHART®
- Broadcast Range: 100m Line of Sight
- RF Bands: 2405 – 2480 MHz
- Nominal Output Power: 8dBm or 0.0063W
Physical Specifications:
- Width at the Base: 54.25mm
- Height: 97.5mm
- Cover Material: Engineered Polymer
- Base Material: SS 316
Operating Conditions:
- Operating Temperature: -40°C to 85°C
- Operating Humidity: 95%, non-condensing

Order and Warranty Information

Terms of Purchase and Returns

Detailed guidelines on minimum order quantity, delivery times, payment options, warranty, and return policies.

We gladly accept bulk orders, with a minimum order quantity of just one unit.

Upon request, we can provide all necessary documents, including Certificates of Origin/Conformance and other required export paperwork.

We accept 100% T/T (Telegraphic Transfer) payment before shipping. For items with lead times, a 30% deposit is required upfront, with the remaining 70% payable before shipment. For RMB transfers, please contact us if you have an agent in China.

All new and original items come with a standard one-year warranty. For extended warranty options, feel free to contact us for pricing details.

We prioritize your satisfaction. If you need to return an item, it must be done within 30 days of purchase. The product must be unused, unopened, and in its original packaging, including all accessories. Refunds will be processed within 5-7 business days of receiving the return. Please note, shipping and handling charges are non-refundable.
