ABB|07 KT 92|Programmable Logic Controller

SKU: 07 KT 92

Manufacturer: ABB
Product No.: 07 KT 92
Condition：In stock
Product Type: Programmable Logic Controller
Product Origin: USA
Payment:T/T, Western Union
Weight: 1700g
Shipping port: Xiamen
Warranty: 12 months

Description

The ABB 07 KT 92 is a programmable logic controller (PLC) from the Advant Controller 31 series for decentralized automation

Features

Supports Function Block Diagram, Ladder Diagram, and Extended Instruction List programming
Serial interface for programming and monitoring
Modular project handling with online status display

Technical Specifications

Processor and Memory:
- User program RAM: 3EE40H bytes
- Flash EPROM: Stores user data segments (0–3) with checksums
- Binary flags: M 00,00 to M 511,15 at SEG:6A80 to SEG:8A80
- Word flags: MW 00,00 to MW 511,15
- Step chains: S 00,00 to S 255,15
Interfaces:
- COM1 serial interface: 9600 baud, 8 data bits, no parity, 1 stop bit
- ARCNET programming: Requires ARCNET card and driver
Operands:
- Digital inputs: E 00,00 to E 63,15
- Digital outputs: A 00,00 to A 63,15
- Analog inputs: EW 00,00 to EW 15,15
- Analog outputs: AW 00,00 to AW 15,15
- System constants: KW 00,00 to KW 00,15
System Functions:
- Cycle time configuration: Via system constants
- Diagnosis flags: M 255,10 to M 255,14 for error states
- Real-time clock: Managed via dual-port RAM
Programming Software:
- 907 PC 33: Supports program memory descriptor 328D to 384D
- Online functions: Single-step execution, breakpoint setting
