Schneider Electric BMEH584040 Redundant Processor Module

Description
Schneider Electric BMEH584040 is a redundant processor module in the Modicon M580 series, designed for high-availability automation systems requiring continuous operation and fault tolerance.

Features
Supports hot-standby redundancy with dual processors (Primary/Standby) and dedicated HSBY port. Enables integrated Ethernet connectivity with service, device, and synchronization ports. Features advanced cybersecurity with Achilles certification, IPSec, embedded firewall, and secure communication. Supports motion control, counters, SSI encoders, HART, and precise timestamping.

Technical Specifications

• Product Range: Modicon M580
• Module Type: Redundant Processor Module
• Rack Capacity: 1 rack
• Remote I/O Stations: 16 (supports X80 and Quantum drops)
• Distributed Devices: Up to 64
• Communication Module Support:
  • 16 Ethernet com. modules
  • 8 AS-Interface modules
• Memory Configuration:
  • Program: 16 MB RAM
  • Data: 2,048 kB RAM
  • System Memory: 10 kB RAM
  • Data Storage: 4 GB Flash (expandable)
• Processing Speed:
  • 30 Kinst/ms (65% Boolean + 35% arithmetic)
  • 40 Kinst/ms (100% Boolean)
• Power Consumption: 360 mA at 24 V DC
• MTBF: 650,000 hours
• Operating Temperature: 0…60 °C
• Storage Temperature: -40…85 °C
• Altitude: Up to 2,000 m (derating above 2,000 m)
• Humidity: 5…95 % at 55 °C, non-condensing
• Protection Rating: IP20
• Vibration Resistance: 3 gn
• Shock Resistance: 30 gn
• Certifications: CE
• Standards Compliance: IEC 61131-2, IEC 61010-2-201, UL/CSA 61010-2-201
• Weight: 0.849 kg
• Packaging:
  • PCE: 9.1 x 18.0 x 25.8 cm, 884 g
  • S03: 30.0 x 30.0 x 40.0 cm, 6 units, 5.770 kg
